Cavern Stairwell
Details
Features
2ft and 4ft Length Stairwell Fixture
7.5″ Width to Cover Existing Footprints (No Painting)
Wall or Ceiling Mount
Two Housing Options:
Cavern (CV):
.060″ Aluminum Body, Cast Aluminum End Plates, Post Paint Finish and Tamper Resistant Screw Option
Cavern Lite (CVL):
.040″ Aluminum Body, Baked on Pre-Paint Enamel
White Standard Finish with Optional Custom Colors
Ultrasonic Sensor Option Provides for Maximum Sensing Range
Impact Resistant Extruded Frosted Acrylic Lens
High Efficacy—Up to 157 lm/W
3000K–5000K CCTs
>80 Color Rendering Index (CRI)
Calculated L70 >100,000 hrs
0–10V Dimmable Driver (100%–10%)
120–277V Universal Voltage
Optional Integral Emergency Battery Backups
ADA Compliant Luminaire
5 Year Warranty
ETL Listed for Damp & Dry Location
DesignLights Consortium® Premium Qualified Luminaire
Applications
Education
Healthcare
Commercial Office
Multifamily
Hotel & Resort
Storage Facility
Retail
Marketing Materials
Cavern Promotion Page
Cavern Brochure
IES Files (.Zip)
Cavern Installation Instructions
Cavern Sensor Programming Instructions
Certifications
Part Number
Watts
Lumens
Lm/W
L70
CRI
DLC
CUT SHEET
IES
CV4-6L-U-40-FRAL
42
5952
144
>100
>80
Premium
CV4-5L-U-40-FRAL
36
5263
145
>100
>80
Premium
CV4-4L-U-40-FRAL
27
4109
151
>100
>80
Premium
CV4-3L-U-40-FRAL
22
3373
154
>100
>80
Premium
CV2-3L-U-40-FRAL
22
3233
150
>100
>80
Premium
CV2-2L-U-40-FRAL
16
2327
145
>100
>80
Premium
